Description
Technical features | sc 2c | |
– cast iron worktable dimensions | [mm] | 1020 x 325 |
– blades tilting | 90° ÷ 45° | |
– max. saw blade diam. with scoring blade installed | [mm] | 315 |
– max. saw blade projection from table at 90°/45° | [mm] | 100/78 |
– max. squaring stroke (standard) | [mm] | 1600 |
– cutting width on parallel fence (standard) | [mm] | 900 (opt 1270mm) |
Other technical features: | ||
– Single-phase motor | 2,2kW (3 Hp) 50Hz | |
Or – Three-phase motor | 4kW (5.5 Hp) 50Hz | |
– exhaust outlet diameter | [mm] | 120 |
