Description
| TECHNICAL FEATURES | lab 300p | |
| Planer: | ||
| – useful working width | [mm] | 300 |
| – cutter block diameter (mm)/n. standard knives | 72/3 | |
| – standard knives dimensions | [mm] | 300 x 30 x 3 |
| – max. stock removal | [mm] | 3 |
| – surfacing tables total length | [mm] | 1300 |
| – thicknessing table dimensions | [mm] | 450 x 300 |
| – feed speed on thicknesser | [m/min] | 7 |
| – min. ÷ max. working height on thicknesser | [mm] | 3 ÷ 220 |
| Circular saw: | ||
| – cast iron saw-spindle moulder worktable dimensions | [mm] | 1020 x 325 |
| – blades tilting | 90° ÷ 45° | |
| – max. saw blade Ø with scoring blade installed | [mm] | 315 |
| – max. saw projection from table at 90°/45° | [mm] | 100/78 |
| – maximum squaring stroke | [mm] | 1600 |
| – cutting width on parallel fence | [mm] | 800 |
| Spindle moulder: | ||
| – max. useful spindle length | [mm] | 100* (70mm with ¾ spindle) |
| – spindle moulder speeds (at 50 Hz) | [rpm] | 3500/7500/10.000 |
| – max. tool diameter when profiling | [mm] | 210 |
| – max. Ø of tool lowered under the table at 90° | [mm] | 180 |
| Other technical features: | ||
| – three-phase motors | 4kW (5,5hp) 50Hz – | |
| Or – single-phase motors | 2.2kW (3hp) 50Hz – | |
| exhaust outlets diameter | [mm] | 120 |
| Spindle moulder available with following diameters: | 30 – 32 – 35 – 40 – 50 mm 3/4″ – 1″ – 1 1/4″ |
